Cryogenic Pipe Shoe
The Cryogenic Pipe Shoe is made for pipe runs where the support point has to carry load without damaging the insulation layer. It is normally ordered by pipe outside diameter, insulation thickness and support height.
Common references include support load 1-80 kN, working temperature range -196°C to 120°C, customized width and bolt hole position, and coating according to site environment.
Description
We manufacture Cryogenic Pipe Shoe for contractors who need a support that can be fitted on site without much adjustment. The shoe body is formed from steel parts, while the insulation or sliding layer is selected by pipe temperature. It is used on chemical plants, LNG lines, power stations and insulated utility pipelines. Before packing, we check weld appearance, size, coating surface and hole position. Drawings are useful, because pipe diameter and insulation thickness change from project to project.
Product Parameters
|
Parameter |
Value |
Notes |
|
Main material |
carbon steel body with insulation block |
by product type |
|
Pipe size |
DN50-DN1200 |
Customized by drawing |
|
Support load |
1-80 kN |
Project reference range |
|
Temperature range |
-196°C to 120°C |
Depends on insulation design |
|
Surface treatment |
Paint / galvanizing |
By site requirement |
|
Installation |
Welded or bolted |
By support layout |
Product Advantages
1. Support height and width can be made by project drawing.
2. Insulation contact area is considered during production.
3. Simple marks on packing help workers match parts on site.
Components
The Cryogenic Pipe Shoe usually includes a steel shoe body, clamp or saddle plate, insulation block or sliding plate, side guide parts, bolt holes and surface coating.
Main Applications
LNG, liquid nitrogen and low-temperature pipeline support points.
Chemical plant pipe racks and utility corridors.
Power station, refinery and storage area pipe supports.
FAQ
Q: How is the size selected?
A: Pipe outside diameter, insulation thickness, load, and movement direction should be checked first.
Q: Can the block material be changed?
A: Yes. PU, red pine wood, or other project material can be discussed when the temperature and pipe size are clear.
Q: Can it be used outdoors?
A: Yes. Surface treatment should match the outdoor condition, and the Cryogenic Pipe Shoe should be selected after the site data is checked.
