Pre-insulated Pipe Shoe
The Pre-insulated Pipe Shoe is made for pipe runs where the support point has to carry load without damaging the insulation layer. It is normally ordered by pipe outside diameter, insulation thickness and support height.
Common references include support load 1-60 kN, working temperature range -50°C to 150°C, customized width and bolt hole position, and coating according to site environment.
Description
We manufacture Pre-insulated Pipe Shoe for contractors who need a support that can be fitted on site without much adjustment. The shoe body is formed from steel parts, while the insulation or sliding layer is selected by pipe temperature. It is used on chemical plants, LNG lines, power stations and insulated utility pipelines. Before packing, we check weld appearance, size, coating surface and hole position. Drawings are useful, because pipe diameter and insulation thickness change from project to project.
Product Parameters
|
Parameter |
Value |
Notes |
|
Main material |
steel base with pre-formed insulation layer |
by product type |
|
Pipe size |
DN50-DN1200 |
Customized by drawing |
|
Support load |
1-60 kN |
Project reference range |
|
Temperature range |
-50°C to 150°C |
Depends on insulation design |
|
Surface treatment |
Paint / galvanizing |
By site requirement |
|
Installation |
Welded or bolted |
By support layout |
Product Advantages
Support height and width can be made by project drawing.
Insulation contact area is considered during production.
Simple marks on packing help workers match parts on site.
Components
The Pre-insulated Pipe Shoe usually includes a steel shoe body, clamp or saddle plate, insulation block or sliding plate, side guide parts, bolt holes and surface coating.
Main Applications
1. chilled water, steam return and insulated process pipelines.
2. Chemical plant pipe racks and utility corridors.
3. Power station, refinery and storage area pipe supports.
FAQ
Q: Is it supplied with the insulation block already fitted?
A: Yes, it can be supplied with the shaped insulation part and steel support together.
Q: Can it be made for sliding pipe movement?
A: Yes. A sliding plate or guide structure can be added when the pipe movement is known.
Q: What information is needed for production?
A: Pipe size, insulation thickness, support height, load direction, and rack drawing are needed before a Pre-insulated Pipe Shoe is made.
