PTFE Lined Pipe Shoe
The PTFE Lined Pipe Shoe is made for pipe runs where the support point has to carry load without damaging the insulation layer. It is normally ordered by pipe outside diameter, insulation thickness and support height.
Common references include support load 1-100 kN, working temperature range -40°C to 200°C, customized width and bolt hole position, and coating according to site environment.
Description
We manufacture PTFE Lined Pipe Shoe for contractors who need a support that can be fitted on site without much adjustment. The shoe body is formed from steel parts, while the insulation or sliding layer is selected by pipe temperature. It is used on chemical plants, LNG lines, power stations and insulated utility pipelines. Before packing, we check weld appearance, size, coating surface and hole position. Drawings are useful, because pipe diameter and insulation thickness change from project to project.
Product Parameters
|
Parameter |
Value |
Notes |
|
Main material |
steel shoe with PTFE sliding plate |
by product type |
|
Pipe size |
DN50-DN1200 |
Customized by drawing |
|
Support load |
1-100 kN |
Project reference range |
|
Temperature range |
-40°C to 200°C |
Depends on insulation design |
|
Surface treatment |
Paint / galvanizing |
By site requirement |
|
Installation |
Welded or bolted |
By support layout |
Product Advantages
Support height and width can be made by project drawing.
Insulation contact area is considered during production.
Simple marks on packing help workers match parts on site.
Components
The PTFE Lined Pipe Shoe usually includes a steel shoe body, clamp or saddle plate, insulation block or sliding plate, side guide parts, bolt holes and surface coating.
Main Applications
1. thermal movement positions on insulated pipelines.
2. Chemical plant pipe racks and utility corridors.
3. Power station, refinery and storage area pipe supports.
FAQ
Q: Why is PTFE used on the PTFE Lined Pipe Shoe?
A: PTFE is used to reduce friction at the sliding contact area when the pipe moves.
Q: Can guide plates be added?
A: Yes. Guide plates can be added when the pipe should only move in one direction.
Q: What should be checked before installation?
A: The sliding face should be clean, the plate direction should match the drawing, and the PTFE Lined Pipe Shoe should be placed on the correct support point.
